STORAGE TANK FABRICATION
| Commencement | Completion | Project Name | Scope of the Project |
|---|---|---|---|
| 2017 | ON-GOING | ETİ BAKIR FERTILIZER COMPLEX, PHOSPHORIC ACID PLANT/ MARDİN, MAZIDAĞI, TURKEY PHOSPHATE PREPARATION UNIT THICKENER TANK AND WATER TANKS FABRICATION AND ERECTION WORKS |
Within the scope of this project; 1 ea. 650m3 SA-516 Gr.70 + RLCS PAP FEED TANK (Ø8500 x 12000mm - 40 ton) 1 ea. 650m3 SA-516 Gr.70 + RLCS THICKENER FEED TANK (Ø8500 x 12000mm - 40 ton) 1 ea. 200m3 S235JR PROCESS WATER TANK (Ø6000 x 7100mm - 9 ton) 1 ea. S355J2 THICKENER (Ø20000 x 6750mm - 47ton) with total weight of 136 ton, 4 units of storage tanks were fabricated to be used at Phosphoric Acid Plant. SIMGETEK`s scope of works comprises of design calculations in accordance with API 650 standards, detailed engineering, preparation of fabrication drawings, supply of the project`s steel materials, fabrication, erection and tests on site. |
| 2017 | 2017 | RECTANGULAR AND CYLINDRICAL TANK FABRICATION | Within the scope of this project; 2x15m3 capacity rectangular tank (2000 x 4300 x 1750mm - 2 ton/pc.) 1x16.5m3 capactiy rectagular tank (2000 x 5500 x 1500mm - 2.5 ton) 1x5.8m3 capacity vertical cylindrical tank (Ø2055 x 1770mm - 1.5 ton) total of 4 uits of SS 304L grade tanks were fabricated. |
| 2016 | 2017 | ATHMOSPHERIC STORAGE TANK FABRICATION | Within the scope of this project; 2 ea. 60m3 S235JR DIESEL&INDUSTRIAL OIL STORAGE TANK (Ø4730 x 3700mm - 7 ton/pc.) 1 ea. 150m3 S235JR AXIAL OIL STORAGE TANK (Ø6630 x 4500mm - 13 ton) 1 ea. 500m3 S235JR DIESEL OIL STORAGE TANK (Ø8450 x 9250mm - 26 ton) 2 ea. 2000m3 S235JR DIESEL FUEL STORAGE TANK (Ø15180 x 12000mm - 67 ton/pc.) with total weight of 187 ton, 6 units of storage tanks were fabricated to be used at oil storage plant. SIMGETEK`s scope of works comprises of design calculations in accordance with API 650, detailed engineering, preparation of fabrication drawings, supply of the project`s steel materials, fabrication, erection and tests on site. |
| 2014 | 2015 | 24M3 SS 304L HORIZONTAL TANK FABRICATION | Within the scope of this project, 4 units of 24 m3 (with dimensions of 2180*8180*1945mm) SS 316L/SS 304L grade prismatic tanks were fabricated. |
| 2013 | 2013 | 20M3 SS 304L HORIZONTAL TANK FABRICATION | Within the scope of this project, 7 units of 20 m3 (with dimensions of 2160*4400*2300mm) SS 304L grade prismatic tanks were fabricated. |
| 2010 | 2010 | VERTICAL CYLINDRICAL SS 304L TANK FABRICATION | Within the scope of this project, 4 units of 4.8 m3 (with dimensions of Ø2055 x 1470mm) SS 304L grade vertical cylindrical stainless steel tanks were fabricated. |
| 2008 | 2008 | STEEL FACTORY GASOMETER PROJECT, TURKEY DRAIN COLLECTION TANK FABRICATION |
Within the scope of this project, 11 units of 5 m3 (with dimensions of Ø1420 x 3200mm) S235JR grade horizontal cylindrical tanks were fabricated. |
| 2008 | 2009 | COMBINED CYCLE POWER PLANT/ BANDIRMA, TURKEY DEMIN WATER TANK & FIRE FIGHTING TANKS FABRICATION AND ERECTION |
Within the scope of this project; 1 ea. 1200m3 SS 304 DEMINERALISED WATER TANK (Ø13000 x 11000mm - 37 ton) 2 ea. 750m3 S235JR FIRE FIGHTING TANK (Ø10000 x 10360mm - 29 ton/pc.) total of 3 units of tanks were fabricated and erected in accordance with API 650 standards. |
| 2007 | 2008 | BTC PIPELINE PROJECT/ GEORGIA KODIANA EMERGENCY DRAIN DOWN TANK FABRICATION |
Within the scope of this project, 450 ton of vessel fabrication and erection along with 50 ton of pipe support and steel fabrication were completed. |
| 2006 | 2007 | HAMRIN OIL FIELD/ IRAQ STORAGE TANK FABRICATION |
Within the scope of this project; 4 ea. 3000m3 FIRE WATER STORAGE TANK (Ø17709 x 12192mm, Total Weight: 98 ton/pc.) 2 ea. 2407m3 CRUDE OIL STORAGE TANK (Ø15854 x 12192mm, Total Weight: 85 ton/pc.) 1 ea. 3989m3 OFF SPEC OIL STORAGE TANK (Ø20422 x 12192mm, Total Weight: 122 ton) 1 ea. 160m3 SLOP/SKIM STORAGE TANK (Ø6098 x 5488mm, Total Weight: 15 ton) 2 ea. 4358m3 FIRE WATER STORAGE TANK (Ø21336 x 12192mm, Total Weight: 130 ton/pc.) 1 ea. 2050m3 FRESH WATER STORAGE TANK (Ø14634 x 12192mm, Total Weight: 78 ton) 1 ea. 160m3 PRODUCED WATER STORAGE TANK (Ø5258 x 7320mm, Total Weight: 15 ton) 1 ea. 2051m3 PROCESS WATER STORAGE TANK (Ø14634 x 12192mm, Total Weight 78 ton) 1 ea. 160m3 PRODUCED WATER STORAGE TANK (Ø5258 x 7320mm, Total Weight: 15 ton) 4 ea. 40m3 DS-4 DIESEL FUEL STORAGE TANK (Ø3200 x 4977mm, Total Weight: 5 ton/ea.) 4 ea. 21m3 DS-4 SERVICE/UTILITY WATER STORAGE TANK (Ø2438 x 4572mm, Total Weight: 4 ton/ea.) 1 ea. 40m3 DIESEL FUEL STORAGE TANK (Ø3200 x 4977mm, Total Weight: 5 ton) 1 ea. 5m3 SKIMMED OIL TANK (Ø1829 x 1829mm, Total Weight: 2 ton) 1 ea. 33m3 SERVICE/UTILITY STORAGE TANK (Ø3048 x 4572mm, Total Weight: 4 ton) 1 ea. 16m3 TEG STORAGE TANK (Ø2896 x 2438mm, Total Weight: 3 ton) with total weight of 1210 ton, 26 units of carbon steel storage tanks comprising of 15 different types were fabricated to be used at oil storage plant. SIMGETEK`s scope of works comprises of design calculations in accordance with API 650 standards, detailed engineering, preparation of fabrication drawings, supply of the project`s steel materials and pre-fabrication. |
